Spring Out Of

Contact Mechanical Seal

Overview

Offering a variegated line of Seal , which is made at par with the international standards. We designed these seals using sophisticated technology for gear pumps. These can bear pressure up to 20 bars and temperature up to 200°C. Our clients can avail these seals at most competitive prices.

spring out of contact mechanical seal

TYPE : HI-SOOC81

Oparating Limits

Shaft Dia 20mm to 100mm (0.75" to 4")
Pressure 20 bar
Temperature -20°C to 200°C
Shaft Speed 2900 RPM (max)

Material of Construction

  • Seal Faces : Carbon, Sic, Ceramic, TC
  • Secondary Seal : EPR, Viton, Silicon, PTFE, Nitrile, Karlez
  • Metal Components : SS 316, SS 304, Hast-C, Alloy-20

Characteristics

  • Single Acting
  • Spring Out of Contact
  • Inside Mounted
  • Hydraulically Balanced Seal Face

Your Partner for Quality Sealing Solutions.

Ask The Experts

Application

  • Petrochemicals
  • General Chemicals
  • Light Hydrocarbons
